Ambient Light Intensity LUX Sensor BH-1750 GY-302

SKU
MD-01698
PKR280.00
Quantity: 11
  • Buy 3 for PKR266.00 each and save 5%
  • Buy 10 for PKR257.60 each and save 8%

Digital light intensity sensor operating in the range of 1 - 65535 Lux (Lux) with resolution of 1 lx or 4 lx depending on the selected mode of operation. It communicates through I2C  interface (TWI), that is, two lines: data - SDA and clock SCL. The module can be used to measure the light intensity both indoors and in the open space. The kit includes a goldpin connector for self-soldering.



Connecting the light sensor

The module has five pins:

Czujnik natężenia światła BH1750

The bottom side of the printed circuit board of the sensor BH1750.



  • VCC - supply voltage: 3 V to 5 V.
  • GND - ground of the system.
  • SCL - the clock line of the I2C bus.
  • SDA - data line of the I2C bus.
  • ADD - address selection of the I2C bus, the indication of the low status sets the address to: 0100011, high: 1011100. The pin is by default in the low status.



The product is compatible with Arduino

  • The sensor can be connected directly to the pins of the microcontroller, e.g. Arduino or minicomputer Raspberry Pi.
  • The user manual is available on our website.
  • Existing library together with the sample code for Arduino can be found on GitHub.
  • In the case of using the Arduino Mega 2560 connected should be pins: SCL with the 21 pin and the SDA with the 20 pin.

Czujnik natężenia światła BH1750 podłączony do Arduino Uno.





Specification

  • Supply voltage: 3 V to 5 V
  • Average current consumption: 120 uA
  • Communication interface: I2C
  • Built-in resistors 4.7 kΩ pulling up the lines SCL and SDA of the I2C bus
  • Built-in voltage regulator
  • Range: 1 to 65535 lx
  • Module dimensions: 21 x 16 x 3.3 mm
Part Number BH1750 GY302
Weight (KG) 0.010000
Product Availability In Stock
