RF Wireless Transceiver Module CC1101 433MHz for Arduino

SKU
MD-00069
PKR750.00
Quantity: 0
Micro-power Wireless data transmission module.Using high Performance TI-chipcons CC1101 Wireless communications chips. The maximum transmission data rates upto 500Kpbs rate can be modify by software.
  • Buy 3 for PKR690.00 each and save 8%
  • Buy 10 for PKR650.00 each and save 13%

Micro-power Wireless data transmission module.Using high Performance TI-chipcons CC1101 Wireless communications chips. The maximum transmission data rates upto 500Kpbs rate can be modify by software.Coverage up to 300~500 meters in open Areas.With a wireless wake up features, sensitivity to -110DBm, High Reliability, Working with 433MHZ frequency band.

Specifications:

  1. Operating voltage: 1.8V ~ 3.6V (recommended 3.3V)
  2. The maximum rate of 500kbps, support 2-FSK, GFSK and MSK modulation
  3. Setup softwafe can modify Rate, Power, Frequency
  4. High sensitivity (1.2Kbps, -110dBm, 0.1% packet error rate)
  5. Built-in hardware CRC error detection, and address control
  6. Lower current consumption (RX, 15.6mA, 2.4Kbps, 433MHz)
  7. Programmable control of output power, up to +10 dBm
  8. Wireless wake-up functionality to support low-power electromagnetic activation, wireless wake-up low-power sleep state of the equipment
  9. Support the transmission channel before the auto-clean-up visits (CCA), the Carrier Sense System
  10. Fast frequency changes brought about by a suitable synthesizer frequency hopping system
  11. Module can be software-based address, software programming is very convenient
  12. Standard 2.0mm DIP spacing interfaces for embedded applications
  13. Separate 64-byte RX and TX data FIFO
  14. Transmission Distance: 300-500 meters in open area (depending on the specific situation of the environment and communication baud rate settings.
  • Related Documents
  • Part Number CC1101
    Manufacturer Made in China
    Weight (KG) 0.003000
