DFRobot: Industrial pH Electrode - Armor Casing - FIT0348

Special Price PKR 10,800.00 Regular Price PKR 11,700.00
In stock
SKU
MD01645
Quantity: 1

Introduction

This pH combination electrode is made of sensitive glass membrane with low impedance.It can be used in a variety of PH measurements with fast response, good thermal stability.It has the good reproducibility, difficult to hydrolysis, and basically eliminate the alkali error .In 0 to 14pH range,the output voltage of the electrode is linear.The reference system which consist of the Ag/AgCl gel electrolyte salt bridge has a stable half-cell potential and excellent anti-pollution performance.The ring PTFE membrane is not easy to be clogged, so the electrode is suitable for long-term online detection.

Note: This is a probe only, and it could be a upgrade part for Analog pH Meter (SEN0161). If you need an industrial long-term pH sensor directly, please check Industrial pH Meter Kit Pro (SEN0169). And the output voltage feedback is from 0 to 5v to indicate pH value from 0 to 14.

Applications

The electrode is suitable for all kinds of printing, circuit board factory, waste water containing chromium and other industrial and domestic sewage pH monitoring.

Specification

  • Length (with protective cover):17.7cm(6.97")
  • Diameter:2.74cm(1.08")
  • Wire Length:5m(196.85")
  • Connector:BNC
  • Measuring Range:0-14pH
  • Measuring Precision: ≦0.02pH
  • Suitable Temperature: 0-60℃
  • Response Time:10sec
  • Drift:≦0.02PH/24hours
  • Resistance of Sensitive Membrane: ≦200*106Ω
  • Slope: ≧95 %
  • Electrode's Equipotential Point:7±0.5PH

Documents

  • WiKi Doc

Shipping List

  • H-101 pH electrode ×1
  • pH electrode manual ×1
More Information
Part Number FIT0348
Manufacturer DFRobot
Weight (KG) 0.200000
Product Availability In Stock
