E6B2-CWZ5B 1024 P/R Rotary Encoder

More Views

E6B2-CWZ5B 1024 P/R Rotary Encoder
SKU: MD-00078
PKR 8,700.00

Availability: Preorder, Delivery in 15-20 Days

This 1024 pulse per rotation rotary encoder outputs gray code which you can interpret using a microcontroller and find out which direction the shaft is turning and by how much.
Description

Details

This 1024 pulse per rotation rotary encoder outputs gray code which you can interpret using a microcontroller and find out which direction the shaft is turning and by how much. This allows you to add feedback to motor control systems. Encoders of this kind are often used in balancing robots and dead reckoning navigation but it could also be used as a very precise input knob.

Specifications:

  1. Resolution: 1024 Pulse/Rotation
  2. Input Voltage: 12 - 24VDC
  3. Maximum Rotating Speed: 6000rpm
  4. Allowable Radial Load: 5N
  5. Allowable Axial Load: 3N
  6. Cable Length: 50cm
  7. Shaft Diameter: 6mm
  • DataSheet
  • Additional Information

    Additional Information

    Part Number N/A
    Manufacturer Made in China
    Weight (g) 400.0000
