LM393 Sound Detection Sensor Module

More Views

LM393 Sound Detection Sensor Module
SKU: SM-00040

Regular Price: PKR 225.00

Special Price PKR 180.00

  • Buy 10 for PKR 170.00 each and save 6%
  • Buy 50 for PKR 155.00 each and save 14%

Availability: Available on Jul 31,2019

It Can be used for Acoustic control light, give sound and light alarm working with Photosensitive sensor ,and sound control,sound detect.
Description

Details

Specifications:




1.Signal output indication.
2.Single channel signal output.
3.Circuit board output switch quantity.
4.The output effective signal is low level.
5.Can detect the intensity of the sound environment.
6.With the retaining bolt hole, convenient installation.
7.When there is sound, outputs low level and the signal light.
8.Can be used for Acoustic control light, give sound and light alarm working with Photosensitive sensor ,and sound control,sound detect.
Note: This sensor only recognizes the availability of sound (vibration principle) can not identify the size of the sound or the specific frequencies of sound.


Module wiring:




1.VCC external 3.3V-5V voltage (which can be connected directly to the 5V MCU and 3.3V chip)
2.GND external GND
3.OUT panel switch quantity output interface (0 and 1)

Additional Information

Additional Information

Part Number No
Manufacturer Made in China
Weight (g) 3.0000
