NXP: Differential Pressure Sensor 0-10KPa - MPX5010DP

SKU
MD-01672
PKR9,650.00
Quantity: 0
  • Buy 3 for PKR9,167.50 each and save 5%
  • Buy 10 for PKR8,878.00 each and save 8%
The MPX5010DP is a dual port, integrated silicon pressure sensor in 6 pin SIP package. This piezoresistive transducer is state of the art monolithic silicon pressure sensor designed for wide range of applications. It is ideally suited for microprocessor or microcontroller based system. This transducer combines advanced micromachining techniques, thin-film metallization and bipolar processing to provide an accurate, high level analogue output signal that is proportional to applied pressure. The axial port has been modified to accommodate industrial grade tubing.
  • On-chip signal conditioned, temperature compensated and calibrated
  • Differential configuration
  • 5.0% maximum error over 0°C to 85°C
  • Durable epoxy unibody
  • Temperature compensated over -40°C to 125°C
  • Patented silicon shear stress strain gauge
  • Pressure range from 0KPa to 10KPa
  • Supply voltage range from 4.75VDC to 5.25VDC
  • Sensitivity of 450mV/mm
  • Response time of 1ms

Applications

Sensing & Instrumentation, Consumer Electronics, Portable Devices, Automation & Process Control, Medical

Part Number MPX5010DP
Manufacturer NXP / Freescale
Weight (KG) 0.010000
Product Availability In Stock
