Owon Digital Bluetooth Multimeter B35T With True RMS

SKU
MD-00414
PKR14,000.00
Quantity: 0
Owon Digital Bluetooth Multimeter B35T With True RMS
  • Buy 3 for PKR13,300.00 each and save 5%
  • Buy 10 for PKR12,600.00 each and save 10%

The B35T is an economical multifunction 3 5/6 digit multimeter, datalogger, and temperature meter that offers true RMS reading and Bluetooth (Android) connectivity for remote measurements. More accurate than 3 ¾ digit meters, the B35T has a large backlit display for easy reading, with an analog bar that gives a visual indication of readings. The smart power-off function extends the battery life.  The temperature measurement functionality uses a K-type thermocouple provided.

SPECIFICATIONS:

  1. DC voltage (60mV – 1000V)
  2. AC voltage (60mV – 750V)
  3. DC current (60uA – 20A)
  4. AC current (600uA to 20A)
  5. Resistance (600 ohm to 60 Mohm)
  6. Capacitance (40nF to 4000uF)
  7. Frequency (9.999Hz to 9.999MHz)
  8. Percentage duty cycle
  9. Temperature (-100degC to +400degC)
  10. Diode test, continuity (buzzer)
  11. Transistor test (hFE)

PHYSICAL DIAGRAM:

 PHYSICAL DIAGRAM

RELATED DOCUMENTS:

  1.  Owon Digital Bluetooth Multimeter B35T With True RMS Manual.

APPLICATIONS:

  1. Electronic circuit debugging
  2. Circuit testing
  3. Design and manufacture
  4. Education and training
  5. Automobile maintenance and testing

PACKAGE INCLUDES:

  1. 1 X Owon Digital Bluetooth Multimeter B35T With True RMS
  2. 1 X Manual
  3. 1 X Multimeter Lead
  4. 1 X Alligator Clip
  5. 1 X Multifunction Test Bench
  6. 1 X K-type Thermocouple
Weight (KG) 0.601000
Manufacturer Owon
Power NA
DC Voltage (V) 60m/600m/60m/600m/6/60/600/1000
AC Voltage(V) 60m/600/60m/600m/6/60/600/750
AC Current (A) 600μ/600μ/6m/60m/600m/6/20
DC Current (A) 600A/600μ/6m/60m/600m/6/20
Resistance (Ω) 600/6k/60k/600k/6M/10M/60M
Frequency 9.999Hz/99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/ 9.999MHz
Frequency Response 40~400Hz
Duty Cycle 0.1%~99.9%
Temperature Range (Min) -50°C
Temperature Range (Max) 400°C
USB/RS232 Interface No
True RMS (TRMS) Yes
Auto Range Yes
Manual Range Yes
Diode Test Yes
Transistor Test Yes
Continuity Test Yes
Bluetooth Interface Yes
Low Battery Indication Yes
Relatively Measuring Yes
Data Hold Yes
Min-Max / Peak Hold Yes
Auto Power-off Yes
Overload Protection No
Shockproof Protection No
Backlight Yes
"Analogue" Bargraph Yes
Size (mm) 2.5” x 2.1”
