Phoenix Contact Relay Module-PLC-RSC-230UC/21-21 - 2967099

SKU
PC-00020
PKR3,150.00
Quantity: 0
Phoenix Contact Relay Module-PLC-RSC-230UC/21-21
  • Buy 25 for PKR2,992.50 each and save 5%
  • Buy 100 for PKR2,898.00 each and save 8%
Phoenix Contact Relay Module-PLC-RSC-230UC/21-21 - 2967099 is available to buy in increments of 10

FEATURES:



  1. Test voltage relay
  2.  winding/relay contact: 4 kV AC (50 Hz, 1 min.)
  3. Test voltage PDT/PDT: 2.5 kV AC (50 Hz, 1 min.)
  4. Operating mode: 100% operating factor
  5. Degree of protection: RT III (Relay)
  6. Mechanical service life: 2 x 107cycles
  7. Flammability rating according to UL 94: V0
  8. Designation: Standards/regulations
  9. Pollution degree: 2
  10. Overvoltage category: III
  11. Mounting position: any
  12. Assembly instructions: In rows with zero spacing



SPECIFICATION:





  1. Connection method: Screw connection
  2. Stripping length: 8 mm
  3. Screw thread: M3
  4. Conductor cross section solid: 0.14 mm² ... 2.5 mm²
  5. Conductor cross section flexible: 0.14 mm² ... 2.5 mm²
  6. AWG conductor cross section: 26 ... 14
  7. Nominal input voltage UN: 230 V AC (220 V DC)
  8. Typical response time: 7 ms
  9. Typical release time: 10 ms
  10. Operating voltage display: Yes
  11. Power dissipation for nominal condition: 1.04 W
  12.

PARAMETERS:







  1. Width: 14 mm
  2. Height: 80 mm
  3. Depth: 94 mm



PACKAGE INCLUDES:










  1. 1 X Phoenix Contact Relay Module-PLC-RSC-230UC/21-21
Part Number 2967099
Weight (KG) 0.069590
Manufacturer phoenix contact
Product Availability In Stock
Packing Unit 10 Pieces
GTIN 4017918156503
Weight per Piece (excluding packing) 69.590 g
Custom tariff number 85364900
