Sinotimer - Single Phase Digital Display Energy Meter DDS528L Din Rail

More Views

Sinotimer - Single Phase Digital Display Energy Meter DDS528L Din Rail
SKU: MD-01276
PKR 1,850.00
  • Buy 3 for PKR 1,810.00 each and save 3%
  • Buy 10 for PKR 1,750.00 each and save 6%
  • Buy 50 for PKR 1,690.00 each and save 9%

Availability: Available on Jun 30,2019

Backlit Single Phase Two Wire LCD Digital Display Wattmeter Power Consumption Energy Meter kWh AC 230V 50Hz Electric Din Rail
Description

Details

Description:

Compared with the traditional meter, this product looks small and beautiful, light weight, easy to install!
The traditional maximum current meter is 4 times the rated current, the product is smart meters, overload capacity
Up to 12 times the base reference current

This product is measured by LCD digital power, no reset button, to avoid human tampering with the data!

Features:

* Rated current: 5A
* Maximum current: 32A
* Pulse frequency: 500imp / kwh
* LCD display with backlight
* Pulse LED indicates working of meter. Pulse output with optical coupling isolation

* 35mm din rail installation

Specification:

Voltage:230V
Supply:AC
Display Type:LCD
Output Voltage:230V
ACDIY Supplies:Electrical
Measuring Energy Range:99999.9
Phase:Single Phase
Accuracy Class:1
Max Operating Current:20A - 49A
OperatingTemperature:-10 to 50℃

Display:Voltage,Current,Frequency,Power,Energy

Package includes:

1 x Energy Meter
1 x User Manual

Additional Information

Additional Information

Part Number DDS528L
Manufacturer Sinotimer
Weight (g) 150.0000
