SEMIKRON SKKT42/12E Thyristors Diode Module

More Views

SEMIKRON SKKT42/12E Thyristors Diode Module
SKU: MD-00071

Regular Price: PKR 5,500.00

Special Price PKR 4,500.00

Availability: Preorder, Delivery in 15-20 Days

SKKT42/12E SEMIKRON Thyristors Diode Module



  1. Heat Transfer through aluminium oxide ceramic Isolated metal baseplate.
  2. Hard soldered Joints for high reliability
  3. UL recognized file no, E 63 532


  1. Current It av: 40A
  2. Gate Trigger Current Max, Igt: 150mA
  3. Gate Trigger Voltage Max Vgt: 3V
  4. Holding Current Max Ih: 150mA
  5. No. of Pins: 7
  6. On State RMS Current IT(rms): 75A
  7. Operating Temperature Max: 125°C
  8. Peak Non Rep Surge Current Itsm 50Hz: 1kA
  9. Peak Repetitive Off-State Voltage, Vdrm: 1.2kV
  10. Thyristor Case Style: Module


  1. DC motors Controls (e.g. for machine Tools)
  2. AC motor Soft Starters
  3. Temperatures Controls (e.g. Ovens, Chemical Processes)
  4. Professional Light dimming (Studios , Theaters)
  • SKKT42/12E SEMIKRON DataSheet
  • Additional Information

    Additional Information

    Part Number N/A
    Manufacturer SEMIKRON
    Weight (g) 200.0000
