TL494 PWM Controller Module 5V 500-100kHz Adjustable Frequency

SKU
MD-00075
PKR700.00
Quantity: 0
TL494 PWM Controller Module 5V 500-100kHz Adjustable Frequency

The TL494 device incorporates all the functions required in the construction of a pulse-width- modulation (PWM) control circuit on a single chip. Designed primarily for power-supply control, this device offers the flexibility to tailor the power-supply control circuitry to a specific application.

Features:

  1. Complete PWM Power-Control Circuitry
  2. Uncommitted Outputs for 200-mA Sink or Source Current
  3. Output Control Selects Single-Ended or Push-Pull Operation
  4. Internal Circuitry Prohibits Double Pulse at Either Output
  5. Variable Dead Time Provides Control Over Total Range
  6. Internal Regulator Provides a Stable 5-V Reference Supply With 5% Tolerance
  7. Circuit Architecture Allows Easy Synchronization

Specifications:

  1. Working voltage:DC 7V-40V
  2. Maximum output current:250mA
  3. Output voltage:DC 5V
  4. Size:23*26mm

Applications:

  1. Desktop PCs
  2. Microwave Ovens
  3. Power Supplies: AC/DC, Isolated,With PFC, > 90 W
  4. Server PSUs
  5. Solar Micro-Inverters
  6. Washing Machines: Low-End and High-End
  7. Power Supplies: AC/DC, Isolated,No PFC, < 90 W
  8. Smoke Detectors
  9. Solar Power Inverters
  • TL494 DataSheet
  • Video Tutorial
  • Part Number NA
    Weight (KG) 0.050000
