Water Level Sensor

Water Level Sensor is a simple and easy to use, great droplets of water levels/recognition sensors, their exposure is through a series of parallel wires the size of water droplets/stitch measurement to determine the water level. Water easy to convert the analog signal, output of the analog values can be directly read by the Arduino Development Board, achieve the effect of water level alarms.

SPECIFICATIONS:

1. Product name: water level sensor
2. Working voltage: DC3-5V
3. Operating current: 20mA
4. Sensor type: analog
5. Detection area: 40mm x 16mm
6. Production: FR4 double-sided HASL
7. Operating temperature: 10 ° c-30 ° c
8. Operating humidity: 10%-90% without condensationv 9) Product weight: 3.5G
9. Dimensions: 62mm x 20mm x 8mm

PACKAGE INCLUDES:

1.  1 X Water Level Sensor
